The method is very simple: download the UiFlow firmware source code, copy the microPython code generated in UiFlow to main.py, change the boot option so that the device runs main.py after powering on, compile the UiFlow firmware, and you will get a .bin file running directly into main.py.

Step 1: Setting up ESP-IDF environment and download UiFlow source code

https://github.com/m5stack/uiflow-micropython
Follow the "How to build" instrument to setting up ESP-IDF environment and clone the UiFlow source code.

Step 2: Change the main.py file and modify boot option

Open up location /m5stack/fs/user/main.py and paste your code generated by UiFlow.
Open up location /m5stack/fs/user/boot.py and edit line 37-40

try:
        boot_option = nvs.get_u8("boot_option")
    except:
        boot_option = 1  # default

into

boot_option = 0

By editing these codes, your device will directly runs main.py after booting. Don't forget to save the files.

Step 3: Build the firmware and flash into your device

Just follow the "Building the firmware" instrument, it will generate a .bin file in /m5stack/build-%YOUR_BOARD_NAME%/ and flash it into your device
Now you have your own .bin with microPython codes, you can publish it in the "User Custom" of M5Burner or other places.

If there is any better or easier way, please discuss it with me.

Hi @scoobysnax
Yes, StampS3 does not have a built-in fuel gauge.
I suggest you make a power supply device yourself, or you can take a look at this new M5StackTimerPWR: https://docs.m5stack.com/en/unit/Unit-TimerPWR
From the official documents and the actual photos, the battery connector of Dial is indeed 1.25mm-2P. I don't understand why the connector you bought is incompatible, or you can take a look at the official power terminal specification: https://m5stack.oss-cn-shenzhen.aliyuncs.com/resource/docs/products/core/M5Dial/1.25WT-2P.pdf.

@teastain
Because the entire framework of UiFlow1 can no longer support the large number of new devices and new functions, UiFlow2 is equivalent to redoing all the functions.
No there is no UiFlow3

@vxgvxg
Yes, these Bases will be adapted to UiFlow2, give it some time

@scaramanga
it should be compatible, but you will need to change the SPI pin.

@sternj
Yes... this feature doesn't seem to be very necessary, custom edit is supposed to be used for some kind of debugging.

@sashaStick5
Если вы уверены, что к прошивке это не имеет никакого отношения, значит экран мертв, обратитесь к дилеру.

@Ruud-Noordermeer
Recently a bug was fixed in userdemo firmware that images cannot post to EZData2. Maybe you can try it again?

@dahult
I just tried these examples and all three can be compiled successfully. Maybe it's your library version problem? Have you installed the board manager correctly?

@ckuehnel
what's you mean for "critical fault #3"?

@Kombistack
System/Time

@jakekinneyactor
Is this what you're talking about?
https://github.com/m5stack/M5Module-DMX512/tree/master/examples

@ioamas
No you do not need a SD card.
Just install drivers, plug in and press upload button.
https://docs.m5stack.com/en/core/core2

@Krmiller
Maybe you should look at the source code of the library to see what it does directly when connecting to the first/second client...I think it's still related to the blockage
