Thanks for sharing that, will definitely print it!

The app seems to be broken. I have tried compiling it as per the instructions on a windows 11 and on a mac. I get the same errors on both. Can anyone please help me? Here is the error code from VS.

Compiling .pio/build/esp-wrover-kit/src/Apps/WiFiWps/WpsConnect.cpp.o
src/Apps/WiFiWps/WpsConnect.cpp: In function 'void wpsInitConfig(bool)':
src/Apps/WiFiWps/WpsConnect.cpp:30:12: error: 'struct esp_wps_config_t' has no member named 'crypto_funcs'
config.crypto_funcs = &g_wifi_default_wps_crypto_funcs;
^~~~~~~~~~~~
src/Apps/WiFiWps/WpsConnect.cpp:30:28: error: 'g_wifi_default_wps_crypto_funcs' was not declared in this scope
config.crypto_funcs = &g_wifi_default_wps_crypto_funcs;
^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
src/Apps/WiFiWps/WpsConnect.cpp:30:28: note: suggested alternative: 'g_wifi_default_wpa_crypto_funcs'
config.crypto_funcs = &g_wifi_default_wps_crypto_funcs;
^~~~~~~~~~~~~~~~~~~~~~~~~~~~~~~
g_wifi_default_wpa_crypto_funcs
src/Apps/WiFiWps/WpsConnect.cpp: In function 'void Wps_run(bool)':
src/Apps/WiFiWps/WpsConnect.cpp:90:27: error: no matching function for call to 'onEvent(void (&)(arduino_event_id_t, system_event_info_t))'
WiFi.onEvent(WiFiEvent);
^
In file included from /Users/redacted/.platformio/packages/framework-arduinoespressif32/libraries/WiFi/src/WiFiSTA.h:28,
from /Users/redacted/.platformio/packages/framework-arduinoespressif32/libraries/WiFi/src/WiFi.h:32,
from lib/M5Stack/M5StackMod.h:30,
from src/Apps/WiFiWps/WpsConnect.h:2,
from src/Apps/WiFiWps/WpsConnect.cpp:8:
/Users/redacted/.platformio/packages/framework-arduinoespressif32/libraries/WiFi/src/WiFiGeneric.h:159:21: note: candidate: 'wifi_event_id_t WiFiGenericClass::onEvent(WiFiEventCb, arduino_event_id_t)' <near match>
wifi_event_id_t onEvent(WiFiEventCb cbEvent, arduino_event_id_t event = ARDUINO_EVENT_MAX);
^~~~~~~
/Users/redacted/.platformio/packages/framework-arduinoespressif32/libraries/WiFi/src/WiFiGeneric.h:159:21: note: conversion of argument 1 would be ill-formed:
src/Apps/WiFiWps/WpsConnect.cpp:90:18: error: invalid conversion from 'void ()(arduino_event_id_t, system_event_info_t)' to 'WiFiEventCb' {aka 'void ()(arduino_event_id_t)'} [-fpermissive]
WiFi.onEvent(WiFiEvent);
^~~~~~~~~
In file included from /Users/readacted/.platformio/packages/framework-arduinoespressif32/libraries/WiFi/src/WiFiSTA.h:28,
from /Users/jredacted/.platformio/packages/framework-arduinoespressif32/libraries/WiFi/src/WiFi.h:32,
from lib/M5Stack/M5StackMod.h:30,
from src/Apps/WiFiWps/WpsConnect.h:2,
from src/Apps/WiFiWps/WpsConnect.cpp:8:
/Users/redacted/.platformio/packages/framework-arduinoespressif32/libraries/WiFi/src/WiFiGeneric.h:161:21: note: candidate: 'wifi_event_id_t WiFiGenericClass::onEvent(WiFiEventSysCb, arduino_event_id_t)' <near match>
wifi_event_id_t onEvent(WiFiEventSysCb cbEvent, arduino_event_id_t event = ARDUINO_EVENT_MAX);
^~~~~~~
/Users/redacted/.platformio/packages/framework-arduinoespressif32/libraries/WiFi/src/WiFiGeneric.h:161:21: note: conversion of argument 1 would be ill-formed:
src/Apps/WiFiWps/WpsConnect.cpp:90:18: error: invalid conversion from 'void ()(arduino_event_id_t, system_event_info_t)' to 'WiFiEventSysCb' {aka 'void ()(arduino_event_t*)'} [-fpermissive]
WiFi.onEvent(WiFiEvent);
^~~~~~~~~
*** [.pio/build/esp-wrover-kit/src/Apps/WiFiWps/WpsConnect.cpp.o] Error 1
========================== [FAILED] Took 6.34 seconds ==========================

The terminal process "platformio 'run'" terminated with exit code: 1. Terminal will be reused by tasks, press any key to close it.

Hello @Steve1

well, there is an alternative method you could use. The power button also acts as regular button. So you could check if the power button was still pressed when M5Paper starts running. Something like this at the beginning of setup():

M5.begin(true, false, true, true, true); M5.RTC.begin(); M5.update(); bool pwrBtnStart = M5.BtnP.isPressed(); // true if started by PWR button

Note: for it to work you'll need to press and hold the power button long enough for the code to reach the statement checking the button. In my tests I need to hold the power button for about 5 seconds.

Note: a disadvantage of the power button check method is that when M5Paper is powered on by USB it thinks it was an RTC start.

Thanks
Felix

Hello @Fortes83

which ESP-IDF version did you use?

I found for the compilation to succeed ESP-IDF version v4.4.6 (as stated here) needs to be used.

Note: I do not (yet) have a M5Cardputer so I cannot verify whether the resulting firmware image runs ok or not.

Thanks
Felix

Does it allow free ringtones?

Thank you for this guidance. I have successfully setup this system, almost exactly, to water a single outdoor plant pot whilst I'm on vacation. I popped the electronics in an adapted waterproof project box. The only disadvantage is that the pot is quite deep so the moisture sensor doesn't go deep enough. The pump works great. However, I've learnt a lot from the experience.

Thank you. I appreciate your hard work.

Has anyone gotten this setup to work. Having issues with the Mac address setup, need help.
Thanks

@haavardmk I dont know the answer to your question., I am experimenting to see which GPIO I can use.

I made a small program on my coresS3, to use gpios 10 and 5 with the rotate/angle unit, and it "works" but hangs oddly for a logn time every several measurements. No idea if that is because GPIO10 is meant to be a "BUS ADC" with some special quality, or some other odd software thing. But it is likely something abuot my device, as I am using wires soldered inside to the 5v pin, GND and the two bus gpio pins on the inside of my DIN base, and gpio10 has its own weird little offset pin on the DIN base pcb

Unfortunately I dont know anything about it but the only documentation I know of is found here: https://github.com/m5stack/M5Unified
